Brand: Genmitsu

Genmitsu 3020-PRO MAX CNC Router Machine for Metal Carving and More

SKU: 101-60-3020PROMAX-E 2 reviews Variants ID: 39624620933199
$499.00
US Free Shipping

Enhanced design and increased Z Height of 72mm with the Genmitsu 3020PRO MAX. The all-metal spindle holder and 300W spindle makes metal carving easier, ideal for an endless variety of drilling, and carving operations on various metals


3rd Batch
Standard Shipping
Ship to
USA
Add to Cart
X

Before purchase, what about a limited sale bundle?


Buy it Now
X

Before purchase, what about a limited sale bundle?


Enhanced design and increased Z Height of 72mm with the Genmitsu 3020PRO MAX. The all-metal spindle holder and 300W spindle makes metal carving easier, ideal for an endless variety of drilling, and carving operations on various metals


About EU Pre-orders:

We are offering pre-order with BFCM limited specials bundle price for EU customers, estimate ship from Feb. 2022.



About UK Pre-orders:

We are still getting ready with the UK certification, please click the NOTIFY ME WHEN AVAILABLE to get the in-stock notification.

  • 300W

    Spindle

  • 72mm

    Height Aluminum Z-Axis

  • 4040 V-Slot

    Extrusion Profile

  • 300X200X72(mm)
    11.8x 7.9x2.8 (in)

    Engraving Area

High Strength

With the all-aluminum body, high rigidity spindle holder and new linear guide structure, the 3020-PRO MAX can easily mill on a wider range of materials with high precision, the increased speed would not compromise the carve.

Redesigned Control Board

Still based on open-source Grbl v1.1, the redesigned control board provides more operational capability and extensibility for the 3020-PRO MAX CNC machine. It integrates the interface for offline controller, XYZ axis limit switches, emergency stop switches, Z-probe and more. Also, it supports the laser engraving (Need to order the laser module separately).

Integrated Scale Aluminum Platform

One-piece machined and molded aluminum design ensures flatness and strength of the platform. Integrated scale design is convenient for material positioning. The platform compatible with most of the CNC clamps on the market.

Easy to Upgrade
Although our standard spindle can already meet the requirements of most projects, the control board and spindle holder still support the upgrade to 600W spindle, making the 3020-PRO MAX more powerful. Also, more and more upgrade accessories will come soon!

SPECIFICATIONS

Test & Review

Specification


Work Area 300 x 200 x 72mm (11.81 x 7.87 x 2.83inch)
Drive System Liner guide & T-nut screw
Control Board Compatibility GRBL 1.1h
Stepper Driver A4988
Stepper Motors 42x48mm
Spindle 300W/12000RPM
Accuracy ±0.1mm
Power Supply 48V/7.3A
CAM Software Candle, Carveco Maker, Easel
Limit Switches Yes
Emergency Stop Yes
Offline Controller Yes
Overall machine size 391 x 461 x 357mm(15.39" x 18.15" x 14.06")
Machine Weight 10.8kg
Rotary 4th Axis Coming Soon
Laser Module Support laser module with 33mm width.
Support OS Windows XP/7/8/10, Linux, Mac OS

What's included


1x 3020-PRO MAX CNC Router Kit 1x English Manual
1x Extension Rod with ER11 Collet (3.175mm) 1x Offline Controller
4x Plate Clamps 1x Emergency Stop
10x 20 Degree Engraving V-Bit 1x Z-Phrobe

Recommended Materials


6061 Aluminum Leather
Copper Plexiglass
Brass Vinyl
Graphite Blocks Resin
Sterling Silver Nylon
Gold PCB
POM PVC
Wood Chipboard
MDF Laminated Veneers
Cast Acrylic Carbon Fiber
Resin Wood

About Wiring

Which CNC is right for you?

Genmitsu 3020-PRO MAX CNC Router Kit, for Metal & Wood Engraving | SainSmart

3018-PRO


300 x 180 x 45mm

11.8 x 7.1 x 1.8in

Working Area


<2h

Assembly Time


Bakelite & Aluminum

Frame


V-slot Linear Rails

Structure


T-track

Spoilboard


DRV8825

Driver Chip


775motor 9kRPM

Spindle Motor


1.3A

Stepper Motor

Genmitsu 3020-PRO MAX CNC Router Kit, for Metal & Wood Engraving | SainSmart

3018-PROVer


300 x 180 x 45mm

11.8 x 7.1 x 1.8in

Working Area


<1h

Assembly Time


All Aluminum

Frame


V-slot Linear Rails

Structure


T-track

Spoilboard


TB67S109

Driver Chip


775motor 10kRPM

Spindle Motor


1.3A

Stepper Motor

Genmitsu 3020-PRO MAX CNC Router Kit, for Metal & Wood Engraving | SainSmart

3020-PRO MAX


300 x 200 x 72mm

11.81 x 7.87 x 2.83in

Working Area


15-30min

Assembly Time


Aluminum and Steel

Frame


Dual Steel X Axis Guide Rails

Structure


Scale Grid

Spoilboard


A4988

Driver Chip


300W 12kRPM

Spindle Motor


XY-1.5A Z-1.8A

Stepper Motor

Genmitsu 3020-PRO MAX CNC Router Kit, for Metal & Wood Engraving | SainSmart

PROVerXL 4030


400 x 300 x 110mm

15.75 x 11.81 x 4.33in

Working Area


<1h

Assembly Time


All Aluminum

Frame


C Beam Structure & Linear Rails

Structure


MDF

Spoilboard


TB6560

Driver Chip


300W 12kRPM

Spindle Motor


2Phase 3A

Stepper Motor
