DSO213 is the latest oscilloscope in the family of SainSmart DSO oscilloscope. Compared with DSO203, DSO213 upgrades its analog bandwidth to 15MHz (DSO203 is 8MHz) and max sample rate to 100MSa/s (DSO203 is 72MSa/s)
Equipped with a 3 inch 400x240 color display, it presents any measured AC current, including sine, square, sawtooth, and triangle waveforms.
Simple to Use
Operation is simple and easy, just like play a smartphone.
Its small form factor conveniently fits inside any pocket so it’s always ready when you need it.
The built-in 8 MB flash storage makes saving and transferring waveform images easier than ever.
Support mobile Android system and computer screens to watch waveforms, it makes measurement become more convenient. Just bring your phone and you can work anytime, anywhere.
Lightweight and portable design, easy to carry. With the USB 2.0 interface, it can be powered over the USB connection, plug, and play. You no longer need to grab an oscilloscope with your colleagues in the lab, and it is easy to carry on a business trip. You can test it whenever you have an idea.
With the new .net architecture, it is more stable and more beautiful, with more reliable compatibility.
Hardware Trigger Function
A single trigger can be carried out in all cases of sampling rate, and the sporadic aperiodic signal can be analyzed.
Record voltage changes for a long time in 72 hours, generate curves, save data.
DS802 can display the voltage waveforms of two independent channels via the real-time data collection.
Lightweight and portable design, easy to carry. With USB 2.0 interface, it can be powered over USB connection, plug and play.
Hardware Trigger Function
Single trigger can be carried out in all cases of sampling rate, and sporadic aperiodic signal can be analyzed.
You can save the screen waveform as a text sample point data file. Take screenshots of the current software interface and the waveform window for later viewing and analysis. The waveform displayed on the screen can generate a print report by the print function at any time.
FFT Frequency Domain Analysis
Real-time display of the amplitude-frequency curve of the fast Fourier transform of the current waveform data. Also it supports AC and DC coupling.
The slim and compact design can fit perfectly inside your pocket, without losing any of the integral features found in a full-sized oscilloscope!
System stores files in BMP, DAT, BUF, or CSV format. Uses a built-in flash disk to save/read waveform images. Math waveforms are as follows: DATA, -DATA, Inp+D, Inp-D, -Inp. Output test signal: 10Hz—1MHz (1-2-5 sequence step). Can be used in a wide range of environments including academic, electronic maintenance, electronic engineering, etc.
The 2.8inch full-color TFT LCD screen provides a rich display for its smaller size.
A built-in 500mAH rechargeable lithium battery provides power for your oscilloscope use, rechargeable through a mini USB port.
Comes with a built-in 8MB storage for saving waveform data and images!
DS212 is a 2-channel digital oscilloscope. It is in a new design - two gear for controlling, very convenient for testing. It supports USB flash disk storage and USB charging. It is widely applicable in the academic experiment, electronic maintenance, electronic engineering tasks, etc.
New design - two gear for controlling, very convenient for testing.
Pocket-size and lightweight.
Chargeable lithium battery, 4 hours' working duration.
This mini oscilloscope is designed for electronic hobbyists to learn about electronics, soldering, programming and STM32. It contains main controller board, TFT LCD and other electronic components to DIY a functional mini digital oscilloscope.
Use STM32 Chip. It runs faster than DSO138 and a good handle of data.
Pre-programmed. The controller board is programmed and tested before leaving factory. It is high quality and safe to use.
Full of Fun. It is a DIY kit and fun to make your own oscilloscope. Especially suitable for who are interested in soldering andSTM32.
With Cool Black Case. Unlike DSO138, SainSmart DSO320 is with a cool black case, which makes it convenient to use in teaching and testing.
Micsig DP20003 is the upgraded Version of DP10013 and more powerful. Maximum Differential Test Voltage( DC + Peak AC) up to 5600V(DP10013: 1300V). Switchable attenuation: 200X, 2000X(DP10013: 50X, 500X)
While Tektronix counterparts, such as P5200A P5205A P5210A, starts at $1,500, Micsig DP20003 offers the same specifications at a reasonable low price.
With portable and simple design, you can take the DP20003 to work anywhere with the small package box. Power supply USB DC 5V output, more portable while oscilloscope has USB interface.
Designed for the measurement of high voltage differential signal, switching power supply design, motor drive design, electronic ballast design, CRT display design, power converter design and service, power device evaluation.
With stable physical properties and high quality plug-in cards, you will get an accurate signal. But please note that a calibration is needed when a substantial change in temperature or other circumstances affect the accuracy of the probe's zero point. You can short the input terminals of the probe, then power the probe while simultaneously pressing the 200X and 2000X keys for 3 seconds.
