TS80P is the upgrade version of TS80 Portable Soldering Iron. It is powered by USB Type-C interface and PD2.0/QC3.0 standard input, which can be powered by charging plugs, power banks and mobile power supplies that comply with the PD2.0 (12V 3A)/QC3.0 (9V 2A) protocol.
Faster Heating
The output power of TS80P has been increased from 18W to 36W max. It can heats up in only 8s from room temperature to 572℉(300 ℃), which is 10s faster than TS80. It’s equipped with an OLED screen, you can monitor the status of the soldering iron at any time.
Smart & Safe
With a built-in STM32 chip, TS80P can smartly control the rise and fall of tip temperature, and features sleep, automatic power-off, safety protection and other modes. The code application layer is open source; you can develop firmware for the soldering iron freely as needed.
More Convenient
TS80P features a brand new easy-push tip fastener, which provides a best holding experience and an easy push to loosen the soldering tip for quick replacement.
Take-and-Go
TS80P has a simple, lightweight body that fits comfortably in the palm of your hand. It’s completely portable and suit your pockets. You can take it anywhere you want and use it while powered by a power bank.
Advantage: 37% lead content effectively lowers melting point and improves the soldering gloss, also saves your work time.
Size: Inside with rosin core, it weighs 500g/ 1.1lbs; The size of solder wire roll is 5.4 x 5.4 x 5.1cm/ 2.1 x 2.1 x 2.0 inches; The diameter of the electrical soldering wire is 0.8mm/ 0.031 inches.
Composition: Sn: 63%; Pb: 37%; Flux: 2%.
Physical Performance: Its melting point is 183°C(361℉); Good fluidity and heats evenly, good thermal and electrical conductivity.
Application: Perfect for electric soldering and wire connections. Such as micro soldering on motherboard, SMD soldering, radios, VCRs, stereos, wires, motors, circuit board.
Advantage: 37% lead content effectively lowers melting point and improves the soldering gloss, also saves your work time.
Size: Inside with rosin core, it weighs 500g/ 1.1lbs; The size of solder wire roll is 5.4 x 5.4 x 5.1cm/ 2.1 x 2.1 x 2.0 inches; The diameter of the electrical soldering wire is 0.6mm/ 0.024 inches.
Composition: Sn: 63%; Pb: 37%; Flux: 2%.
Physical Performance: Its melting point is 183°C(361℉); Good fluidity and heats evenly, good thermal and electrical conductivity.
Application: Perfect for electric soldering and wire connections. Such as micro soldering on motherboard, SMD soldering, radios, VCRs, stereos, wires, motors, circuit board.
Advantage: 37% lead content effectively lowers melting point and improves the soldering gloss, also saves your work time.
Size: Inside with rosin core, it weighs 100g/ 0.22lbs; The size of solder wire roll is 5.4 x 5.4 x 5.1cm/ 2.1 x 2.1 x 2.0 inches; The diameter of the electrical soldering wire is 0.6mm/ 0.024 inches.
Composition: Sn: 63%; Pb: 37%; Flux: 2%.
Physical Performance: Its melting point is 183°C(361℉); Good fluidity and heats evenly, good thermal and electrical conductivity.
Application: Perfect for electric soldering and wire connections. Such as micro-soldering on motherboard, SMD soldering, radios, VCRs, stereos, wires, motors, circuit board.
Advantage: 37% lead content effectively lowers melting point and improves the soldering gloss, also saves your work time.
Size: Inside with rosin core, it weighs 100g/ 0.22lbs; The size of solder wire roll is 5.4 x 5.4 x 5.1cm/ 2.1 x 2.1 x 2.0 inches; The diameter of the electrical soldering wire is 1mm/ 0.039 inches.
Composition: Sn: 63%; Pb: 37%; Flux: 2%.
Physical Performance: The melting point is 183°C(361℉); Good fluidity and heats evenly, good thermal and electrical conductivity.
Application: Perfect for electric soldering and wire connections. Such as micro soldering on motherboard, SMD soldering, radios, VCRs, stereos, wires, motors, circuit board.
Advantage: 37% lead content effectively lowers melting point and improves the soldering gloss, also saves your work time.
Size: Inside with rosin core, it weighs 100g/ 0.22lbs; The size of solder wire roll is 5.4 x 5.4 x 5.1cm/ 2.1 x 2.1 x 2.0 inches; The diameter of the electrical soldering wire is 0.8mm/ 0.031 inches.
Composition: Sn: 63%; Pb: 37%; Flux: 2%.
Physical Performance: The melting point is 183°C(361℉); Good fluidity and heats evenly, good thermal and electrical conductivity.
Application: Perfect for electric soldering and wire connections. Such as micro soldering on motherboard, SMD soldering, radios, VCRs, stereos, wires, motors, circuit board.
Lead-Free: Lead free solder is better for your job as well as the environment.
Size: Inside with rosin core, it weighs 100g/ 0.22lbs; The size of solder wire roll is 5.4 x 5.4 x 2.8cm/ 2.1 x 2.1 x 1.1 inches; The diameter of the electrical soldering wire is 1mm/ 0.039 inches.
Physical Performance: The melting point is 227°C(440.6℉); Good fluidity and heats evenly, good thermal and electrical conductivity.
Application: Perfect for electric soldering and wire connections. Such as micro soldering on motherboard, SMD soldering, radios, VCRs, stereos, wires, motors, circuit board.
Lead-Free: Lead-free solder is better for your job as well as the environment.
Size: Inside with rosin core, it weighs 100g/ 0.22lbs; The size of solder wire roll is 5.4 x 5.4 x 2.8cm/ 2.1 x 2.1 x 1.1 inches; The diameter of the electrical soldering wire is 0.8mm/ 0.031 inches.
Physical Performance: The melting point is 227°C(440.6℉); Good fluidity and heats evenly, good thermal and electrical conductivity.
Application: Perfect for electric soldering and wire connections. Such as micro soldering on motherboard, SMD soldering, radios, VCRs, stereos, wires, motors, circuit board.
Lead-Free: Lead-free solder is better for your job as well as the environment.
Size: Inside with rosin core, it weighs 100g/ 0.22lbs; The size of solder wire roll is 5.4 x 5.4 x 2.8cm/ 2.1 x 2.1 x 1.1 inches; The diameter of the electrical soldering wire is 0.6mm/ 0.023 inches.
Physical Performance: The melting point is 227°C(440.6℉); Good fluidity and heats evenly, good thermal and electrical conductivity.
Application: Perfect for electric soldering and wire connections. Such as micro soldering on motherboard, SMD soldering, radios, VCRs, stereos, wires, motors, circuit board.
This is a TS80 soldering iron accessory kit that ensures TS80 soldering iron works in its standard voltage. Come with quick charger 3.0 power supply and USB type-c cable.
TS80 is a newly designed smart soldering iron, suitable for hobbyists, tinkerers, or electrical engineers doing the most precise repair jobs.
Smart
The integrated STM32 processor automatically regulates the TS80’s “sleep”, “standby”, and “operating” modes, ensuring a safe operation for the user. Equipped with an OLED screen, giving feedback on the TS80’s operation status.
More Portable
Driven by the pursuit of perfection, TS80 is a smaller and thinner soldering iron than its ancestor TS100. This unit is powered by USB Type-C interface and QC3.0 standard input. It can be powered using any mobile power supply that meets the QC3.0 (9V 2A) protocol. TS80 is ready for work anytime!
More Durable
The body of the TS80 is made of a CNC machined aluminum alloy. This provides you with a small, but robust package designed to last!
Excellent Temperature Control
The internal ceramic heating core and pure copper heating conductor focuses the heat to the iron’s tip, ensuring easy, reliable, and consistent operation for all jobs!
Code Application Layer Open Source
The TS80’s firmware is open source, allowing for customized adjustment of the iron’s parameters and behavior!
The Pro32 is a staple tool for the hobbyist, tinkerer, or electrical engineer. Featuring a sleek body, complete with temperature adjustment buttons and an OLED display, the Pro32 feels good in the hand and offers a wide temperature range for operation. Its internal heating element warms up to operating temperature in just 12 seconds!
Rapid Warmup
With the help of dual temperature sensors, the internal heating element reaches its operating temperature extremely fast—just 12 seconds! The tip temperature can be set between 212° F and 752° F (100° C to 400° C) using the adjustment buttons and OLED display.
New Power Supply Design
The Pro32 features an integrated DC5525 12-24V connection. Its anti-static design isolates the temperature sensors from extraneous surges.
Tough & Portable
The sleek, slim design is comprised of an SAE 304 stainless steel core, housed inside a polycarbonate shell with an easy-to-read OLED display.
Smart & Safe
The integrated STM32 processor chip automatically regulates the Pro32’s “sleep mode”, “standby”, and “operating mode”, ensuring the safety of the user.
SainSmart 599B is a replacement solder tip cleaning wire sponge. These sponges are hard enough to remove debris and some corrosion from the solder tips while being soft enough not to damage the tip. They help to remove oxides and excess solder to preserve tip life and enable clean, precise soldering. It is a good cleaning sponge for SainSmart Pro32 soldering iron!
