Description:

Banana PI M1 is the open source hardware platform which published to assistant the Elastos.org open source OS, Banana PI M1 is the dual core Android 4.2 product which more better than the Raspberry Pi.
Banana Pi M1 series run Android,Debian linux,Ubuntu linux, Raspberry Pi imange and cubieboard imange. Elastos coordinate multi CUP to from the family cloud entirnment which based on the “software/hardware serviceâ€?Banana PI hardware: 1Ghz ARM7 dual-core processor, 1GB DDR3 SDRAM, Banana PI with Gigabit ethernet port, SATA Socket. It can run with Android 4.2.2 smoothly.
The size of Banana PI M1 like the credit card, it can easily run with the game it support 1080P high definition video output, the GPIO compatible with Raspberry Pi and can run the ROM Image directly.





Specification:



Model

KB06

CPU

A20 ARM Cortex-A7 Dual-Core

RAM

1G DDR3 (share with GPU)

Flash

Up to 64GB on SD slot,up to2T on 2.5 SATA disk

LAN

10/100/1000 Ethernet RJ45

Wifi

Option

Video Input

A CSI input connector allows for the connection of a designed camera module

Video Out

HDMI , CVBS , RGB/LVDS

Audio Output

3.5 mm jack

Power Source

5 volt via MicroUSB(DC In Only)and/or MicroUSB(OTG)

USB 2.0 Ports

2(direct from Allwinner A20 chip)

Buttons

Reset button:Next to MicroUSB connector

Power button:Next to Rest button

Boot button (Optional):Behind HDMI connector

GPIO(2*13)pin

GPIO,UART,I2C bus,SPI bus with two chip selects,CAN bus,ADC,PWM,+3.3v,+5v,ground

LED

Power Key&RJ45

Remote

IR(Optional)

OS

Android 4.2,Firefox OS and Linux ect.OS

Product size

92mm*60mm

Weight

48g
