NEMA-23 2-Phase 4-Wire 1.2A 56mm 1.8° Stepper Motor for 3D Printing & CNC

brand: SainSmart SKU: 101-91-213 Variants ID: 45102746964
  • High torque motor for 3D printer and CNC
  • Precisely machined full metal body
  • High-quality black powder paint
  • Minimized heat gain for continuous run
  • "D" shaft for easy and secure coupler connection
$23.99
SPECIFICATION
    • Shaft diameter 6.35 mm;
    • Shaft length 20 mm.
    • Step Angle 1.8°
    • Step Accuracy 5%
    • Holding Torque 1.3N·m (184oz·in)
    • Rated Current/phase: 2.5 A Phase
    • Resistance 1.6 ohms
    • Rated Voltage (≠driving voltage) 4V
    • Inductance 3.8 mH ±20%
    • Weight 720 g
    WHAT’S IN THE PACKAGE
    • 1x Stepping motor
    • 1x Cable
