[Discontinued] NEW Hantek DSO5102P USB Digital Storage Oscilloscope 2 Channels 100MHz 1GSa/s
Brand: Hantek SKU: 20-010-705

[Discontinued] NEW Hantek DSO5102P USB Digital Storage Oscilloscope 2 Channels 100MHz 1GSa/s

SKU: 20-010-705 Variants ID: 45101477524
$274.42
Free Shipping


Description:
Features:

  • 70MHz bandwidths
  • 1GSa/s Real Time sample rate
  • Large (7.0-inch) color display, WVGA(800x480)
  • Record length up to 40K
  • Trigger mode: edge/pulse width/line selectable video/slop/overtime etc.
  • USB host and device connectivity, standard
  • Multiple automatic measurements
  • Four math functions, including FFTs standard
  • Provides software for PC real-time analysis



Specification:

Model

DSO5102P

Bandwidth

70MHz

Channel

2

Real-Time Sample

1GSa/s

Equivalent Sample

25GSa/s

Memory Depth

40K

Rise Time

5ns

Time Base Accuracy

±50ppm

Time Base Range

8ns/div-40s/div

Input Impendance

 1MΩ

VOLTS/DIV Range

2mV/div~5V/div

A/D Converter

8 bit

Position Range

±50V(5V/div), ±40V(2V/div~500mV/div),
±2V(200mV/div~50mV/div),±400mV(20mV/div~2mV/div)

DC Gain Accuracy

±3% for Normal or Average acquisition mode, 5V/div to 10mV/div;
±4% for Normal or Average acquisition mode, 5mV/div to 2mV/div

Bandwidth Limit

20MHz

Trigger Types

Edge, Video, Pulse, Slope, Over time, Alternative

Trigger Source

CH1, CH2, EXT, EXT/5, AC Line

Math

+,-,x,÷,FFT

Cursor Measurement

Voltage difference between cursors: ?V;
Time difference between cursors: ?T;
Reciprocal of ?T in Hertz (1/ΔT);

Auto Measuerment

Frequency, Period, Mean, Pk-Pk, Cycli RMS, Minimum, Maximum, Rise time, Fall Time,

+Pulse Width, -Pulse Width, Delay1-2Rise, Delay1-2Fall, +Duty, -Duty, Vbase, Vtop, Vmid,

Vamp, Overshoot, Preshoot, Preiod Mean, Preiod RMS, FOVShoot, RPREShoot, BWIDTH? FRF

Display

7"TFT 16K Color LCD, 800*480 dots

Size

313mm x 108mm x 142mm

Weight

2.08KG

Standard Probe

PP90

Software: Operating system: Windows 7, Windows NT, Windows 2000,Windows XP, VISTA




Package List:

  • 1x DSO5072P Oscilloscope
  • 2x Probe
  • 1x USB Cable
  • 1x Power Cord
  • 1x CD( Mannual,etc.)
