[Discontinued] OWON HDS3101M-N Hand Oszilloskop 100MHZ+ Multimeter handheld Scopemeter

Specifications

Bandwidth

100 MHz

Sample rate(Real time)

1 GS/s

Horizontal Scale(S/div)

5 ns/div ~ 100 s/div, step by 1~2~5

Rise time (at input, typical)

3.5 ns

Channels

Single

Display

3.7 inch color display with TFT panel (640×480 pixels)

Input impedance

1 MΩ ± 2% in parallel with 15 pF ± 5 pF

Probe attenuation factor

1X,10X,100X,1000X

Max. input voltage

400 V (PK - PK) (DC + AC, PK - PK, 1MΩ input impedance, probe attenuation 10 : 1), CAT II

Record length

Max. 6000 points on each channel

Interpolation

(sin x)/x

Input coupling

DC, AC, GND

Acquisition modes

Sample, Peak Detect and Average

Vertical resolution (A/D)

8 bit

Vertical sensitivity

5 mV/div ~ 5 V/div(at input)

DC gain accuracy

±3%

DC accuracy (Average)

Average > 16: ± (3% reading + 0.05 div) for ΔV

Trigger type

Edge, Video, Alternate

Trigger mode

Auto, Normal, Single

Trigger level

±6 divisions from screen center

Waveform math

+, -, ×, ÷, FFT

Waveform storage

4 waveforms

Communication interface

USB

Cymometer

Available

Power supply

100 V - 240 V AC, 50/60 Hz

Multimeter Specification

Full scale reading

3 3/4 digits (Max.4000-count)

Input Impedance

10 MΩ

Capacitance

51.2 nF - 100 uF: ± (3% ± 3 digit)

Voltage

VDC: 400 mV, 4 V, 40 V, 400 V, 1000 V: ± (1% ± 1 digit); max input : DC 1000 V
VAC : 4 V, 40 V, 400 V: ± (1% ± 3 digits), 750 V: ± (2% ± 3 digits);
Frequency : 40 Hz - 400 Hz; max input : AC 750 V (virtual value)

Current

DC: 40 mA, 400 mA: ± (1.5% ± 1 digit), 20 A: ± (3% ± 3 digits)
AC: 40 mA: ± (1.5% ± 3 digits), 400 mA: ± (2% ± 1 digit), 20 A: ± (5% ± 3 digits)

Impedance

400 Ω: ± (1% ± 3 digits), 40 ΚΩ - 4 ΜΩ: ± (1% ± 1 digit), 40 MΩ: ± (1.5% ± 3 digits)
