Features:
- Low power consumption
- High sensitivity to methane
- Long life and low cost
- Uses simple electrical circuit
Application examples:
- Domestic gas alarms
- Portable gas detectors
- Gas leak detector for gas appliances
Specifications:
|
Target gases |
Methane |
|
Typical detection range |
500 - 10,000ppm |
|
Sensing principle |
MOS type |
|
Driving voltages |
Heater Voltage:5.0V |
|
Power consumption |
280mW |
|
Dimensions |
φ9.2×12.4mm |
|
Weight |
Approx. 1.4g |
