SainSmart Graphics Display M328 Inductor Capacitor ESR Table Tester Meter LCR

brand: SainSmart SKU: 101-92-139
$18.98
Oops, 0 In Stock

Description:
Multifunctional transistor tester for the automatic recognition of NPN and PNP transistors, N-channel and P-channel MOSFETs, diodes, thyristors, resistors, capacitors or other means. Easy and convenient to use.


Features:

  • The display is 12864 LCD backlit in white.
  • Powered by 3.7V lithium battery (not included) or 5V external power source with USB port (USB cable is not included).
  • Recognize NPN and PNP transistors, N-channel and P-channel MOSFET, JFET, diodes, inductors, resistors, condensers, thyristors or other devices automatically.
  • Automatically test the pins of a component and show on the display.
  • Measurement of the gate threshold voltage and the gate capacitance of the MOSFET.
  • Measure. Bipolar transistor current gain and the base-emitter threshold voltage
  • Short Detection Time: 2 seconds. It takes more time for large capacitor detection.



Technical Specifications:

  • Material: PCB
  • Display: LCD 12864
  • Battery: 3.7V lithium battery Model: 14500 (not included)
  • Item Size: 7.3 * 7.1 * 1.5 cm / 2.9 * 2.8 * 0.6in
  • Item Weight: 41g / 1.4 oz
  • Package Size: 10 * 8.5 * 2cm / 3.9 * 3.3 * 0.8 In
  • Package Weight: 46g / 1.6 oz



Documents:
Click to download the manual


Package List:

  • 1xESR Meter (not included Battery )
  • 3xTest line
