Siglent SDS1102X-S Super Phosphor Oscilloscope Bandwidth 100MHz 8 inch TFT LCD+AW

brand: SainSmart SKU: 20-010-435 Variants ID: 45101701972
Oops, 0 In Stock


  • SIGLENT's new SDS1000X Series Super Phosphor Oscilloscopes are available in four bandwidths, 100 MHz and 200 MHz, a sample rate of 1 GSa/s, and a standard record length of 14 Mpts. The most commonly used functions can be accessed with its user-friendly one-button design.
  • 200MHz, 100MHz, bandwidth models
  • Real-time sampling rate up to 1GSa/s
  • Record length of 14Mpts
  • Waveform capture rate up to 60,000 wfs/s
  • New generation of SPO technology
  • Supports 256-level intensity grading and color temperaturedisplay
  • Intelligent trigger: Edge, Slope, Pulse, Window, Runt, Interval,
  • Time out (Dropout), Pattern
  • Serial bus triggering and decode, supports protocols I2C, SPI, UART/RS232, CAN, LIN
  • Video trigger, supports HDTV
  • Low background noise, supports 500μV / div to 10V / div voltage scales
  • 10 types of one-button shortcuts, supports Auto Setup, Default Setup, Cursor, Measure, Roll, History, Persistence, Clear Sweep, Zoom and Print
  • Bandwidth :100MHz
  • Sample Rate(Max): 1GSa/s
  • Channels:2+EXT
  • Memory Depth(Max) 7Mpts/CH (Dual-Channel); 14Mpts/CH (Single-Channel)
  • Waveform Capture Rate 60,000 wfms/s
  • Trigger Type Edge, Slope, Pulse width, Window, Runt, Interval, Dropout, Pattern, Video
  • Serial Trigger (Optional) I2C, SPI, UART/RS232, CAN, LIN
  • Decode Type (Optional) I2C, SPI, UART/RS232, CAN, LIN
  • DDS Waveform Generator No Yes No Yes
  • Single Channel, Max Frequency up to 25MHz, 125 MS/s waveform generation Capabilities, wave length 16Kpts I/O USB Host, USB Device, LAN, Pass/Fail, Trigger Out, 1KHz Cal
  • Probe(Std) 2 pcs passive probe PP510 2 pcs passive probe PP215
  • Display 8 inch TFT LCD (800x480)
  • Weight Net weight 3.26 Kg, Gross weight 4.25Kg
