SainSmart Blue Laser Module Kit for Genmitsu CNC Machine 3018-PRO/3018/ 1810-PRO
Brand: SainSmart SKU: 101-60-285 23 SKU: 101-60-285SainSmart Blue Laser Module perfectly match the SainSmart Genmitsu CNC router kit. With this module, it can absolutely give you different ways to unleash your creativity.
Industrial Grade Design
SainSmart Blue Laser Module is designed for the industrial laser engraving machine, it adopts an intelligent feedback control circuit, external ACC constant current driving Mode. Featuring with reliability, high stability, high efficiency, low noise, and excellent laser beam quality.
Excellent Heat Dissipation
Equipped with large aluminum heatsink and cooling fan, this can help the heat dissipate fast and ensure the laser module works continuously.
Easy to Use
No instructions needed, just plug it to the laser port of the driver board, then it works.
Focus Adjustable
The focus of the laser lens can be adjustable according to your need. This operation can be done by spinning the laser lens.
Application
The laser module is ideal for engraving, cutting, scribing, and drilling. Desired patterns can be made easily on the wood or plastic by this unit.
Tips: When Purchased With SainSmart Genmitsu CNC Router, Two Products Will Be Delivered Separately. These Laser Modules Are Not Compatible with 3018-MX3 and 3018 PROVer.
Click Here To See Blue Laser Module Review
Note
- Please wear laser goggles during usage, avoid to touch the laser directly to the eyes and skin.
- In order to avoid unexpected accident happens, please stay with the machine while the laser module is working.
SPECIFICATION
- Heatsink material: aluminum
- Output power: 2.5W (5.5W)
- Wave length: 445nm blue laser
- Voltage: 12V
- Current: 2A
- Beam shape: Dot (focus adjustable)
- Lift time: >10,000 hours
- Working temperature: -40~75℃
- Can engrave: MDF/ Balsa/ Paper / Wood/ Fabric/ Plastic/ Leather/ Plywood/ Foam Paper/ Anodized Aluminum
- Can not engrave: Metal/ Glass/ PCB/ Transparent Material
WHAT’S IN THE PACKAGE
- 1x SainSmart Blue Laser Module for CNC Router 3018, 3018-PRO, 1810-PRO
- 1x goggles
- 1x mounting material (2 x T-nut and 2 x screw for mounting on aluminum profile)
- Reviews
- Questions
United StatesGreat! Setup was easy, followed James Dean Designs YouTube video on setting it up and we're off and burning!!!
United StatesIt works great once I figured out how to connect it to my control board. I have a 2018PROVer and my control board does not have a mating jack to plug the unit into. I had to solder my wires directly to the pins on my board. My board has two separate jacks and not one as pictured in the instructions.
United StatesI had no issues installing and setting up the laser using the documentation provided. The laser worked as expected and I’ve already etched and cut a few small things. Very happy with this purchase and will continue to purchase from this company!
United StatesAwesome works amazingly I've been doing some real quality laser engraving thanx to this thing
United StatesI'm in love with this thing
United StatesGreat customer service and products. Happy to do business with your company.
United StatesThe laser is definitely powerful enough for a hobby laser. Probably wouldn't want too much more powerful for a non-enclosed and ventilated case.
United StatesThe product is good and simple to setup. But note that you are getting only 5W so you are limited by the cutting capability.
United StatesLoved the ease of assembly and the intuitive instructions for operation.
United Stateseasy to install, perfect for the home hobbiest.
Software Links
LaserGRBL The best free GCode sender for DIY Laser Engraver. LaserGRBL is able to load and stream GCode path to arduino, as well engrave images, pictures and logo with internal conversion tool.
LightBurn is a premium version of LaserGRBL which allows you powerful tools for editing, adjusting the layout and controlling your laser. LightBurn is a native application written for Windows, Mac OS, and Linux. Can click here to buy the LightBurn GCode License Key.
